EKU Clipo 15 GKK Infront
ESLD - 1203
EKU Clipo 15 GKK Infront
Features of the ENOX Glass Sliding Fitting For Small Cabinet ESLD - 1203
- Top track, groove mounted.
- No groove in the floor.
- Without fascia.
- With running gear for concealed fixing.
- For 2 glass door.
- Aluminium glass fixing profile 16 / 10 mm.
- Maximum Glass Weight : 15kgs/Panel.
| ESLD - 1203 - 2 Doors Kit |
|
ESLD - 1203 - 2
EKU Clipo - 15 GKK Infront
| |
| ESC - 1201 - A |
|
| ESC - 1201 - A
Aluminium anodized single sliding track non-drilled.
Features : - Finish : Aluminium anodized.
- Size : 3500mm.
| |
| EGSF - 007 - 2 Doors Kit |
|
| ESC - 1202 - C - 250
Aluminium anodized single sliding track non-drilled.
Features : - Finish : Aluminium anodized.
- Size : 2500 / 3500mm.
| |
| Ordering Information for ESLD - 1203(Cabinet Sliding Fitting - Glass Sliding Solution) |
| Product Code | ESLD - 1203 - 2 | ESC - 1201 A | ESC - 1202 - C |
| Quantity for 2 doors | 1 Set | 1 Pcs | 1 Pcs |
| Abbrevations: DW - Door Width / ICW - Internal Cabinet Width / DH - Door Height / ICH - Internal Cabinet Height |
